🍄 Beat by Beat: Engineering a 'Gnomecore' 3D Metronome in Godot 4.6

Every developer has a list of "micro-projects" they build to keep their skills sharp or blow off some steam. For me, that recently took the form of Metrognome, a whimsical 3D metronome built from scratch using the Godot 4.6 engine and pure GDScript.

The concept is simple: a line of garden gnomes stands in a mushroom grove, bouncing to the beat. If you select a 5/4 time signature, you get five gnomes. On the downbeat (or accents), the respective gnome does a high, dramatic leap; on regular beats, a short bounce.

But under the hood of this cozy, "gnomecore" aesthetic lies a series of classic real-time systems problems: procedural audio synthesis, custom spatial layout algorithms, and stateful physics-like animation loops.

Let's tear down the architecture and see how it works.

🔊 Procedural Audio: Generating Clicks in Real Time

In a standard game, if you want a click or a beep, you load a .wav file. For a metronome, this has two downsides:

It bloats the asset size (even slightly).
It lacks customization. If you want a different pitch, you have to pitch-shift the sample, which can introduce artifacts.

Instead, I opted for procedural audio synthesis using Godot's AudioStreamGenerator and AudioStreamGeneratorPlayback. Every tick, the application generates raw PCM audio data in memory and pushes it to the audio buffer.

Here is the math: a click is just a sine wave that decays exponentially over time. By combining a frequency (pitch) with an exponential decay multiplier (e^-t), we get a clean, punchy click:

func _generate_frames(frequency: float, duration: float, amplitude: float) -> PackedVector2Array:
	var total_frames := int(_sample_rate * duration)
	var frames := PackedVector2Array()
	frames.resize(total_frames)
	for i in total_frames:
		var t := float(i) / float(_sample_rate)
		var envelope := exp(-t * 50.0) # Decay multiplier
		var value := sin(2.0 * PI * frequency * t) * envelope * amplitude
		frames[i] = Vector2(value, value) # Stereo
	return frames

In audio_clicker.gd, I pre-calculate arrays of these frames for three different sound types:

Click: High-pitched sine wave (1200Hz base / 1600Hz accent) with a short 0.025s duration.
Wood Block: Lower, woody resonance (500Hz base / 700Hz accent) with a slightly longer 0.04s decay.
Beep: Mid-range electronic tone (900Hz base / 1300Hz accent).

When the metronome ticks, _playback.push_frame() feeds the buffer, yielding latency-free, mathematically perfect beats.

⏱️ The Metronome Core & Time Signatures

A metronome is only as good as its timing. In game engines, doing timing inside _process using delta (frame time) requires care. If you just check if a timer exceeds an interval, frame rate fluctuations can cause drift.

To combat this, metronome.gd uses a time accumulator that subtracts the interval once reached, preserving sub-frame precision:

func _process(delta: float) -> void:
	if not _is_playing:
		return
	_time_accumulator += delta
	if _time_accumulator >= _tick_interval:
		_time_accumulator -= _tick_interval # Retain leftover remainder to avoid drift
		var is_accent := _current_beat < accent_pattern.size() and accent_pattern[_current_beat]
		tick.emit(_current_beat, _beats_per_measure, is_accent)
		beat_changed.emit(_current_beat)
		_current_beat = (_current_beat + 1) % _beats_per_measure

By subtracting _tick_interval instead of setting the accumulator back to 0.0, any sub-frame timing errors are carried over and resolved in the next frame, maintaining long-term drift-free accuracy.

🍄 Bouncing Gnomes & Opossums: Real-time 3D Math

Once the metronome ticks, the visual elements react. The gnomes are arranged in a horizontal line. On their designated beat, they execute a vertical arc.

Instead of writing a complex state machine or using Godot's animation player for a simple bounce, the vertical displacement is calculated using a half-sine wave:

$$y = \sin(t \cdot \pi) \cdot h_{max}$$

Where $t$ ranges from 0.0 (start of bounce) to 1.0 (end of bounce), and $h_{max}$ is the maximum bounce height (larger for accented beats).

func _process(delta: float) -> void:
	if not _is_bouncing:
		return
	_bounce_timer += delta
	if _bounce_timer >= bounce_duration:
		_bounce_timer = bounce_duration
		_is_bouncing = false
		position = _original_position
		return
	var t := _bounce_timer / bounce_duration
	var height := sin(t * PI) # Half-sine wave arc
	var max_height := accent_bounce_height if _is_accented else base_bounce_height
	position = _original_position + Vector3.UP * height * max_height

The Opossum Wanderer

To add character, I populated the scene with local wildlife. A small opossum model walks a randomized curvy path around the mushroom forest while the metronome is active. To make its movement feel natural rather than rigid, the heading vector is modulated by a sine wave over time:

_opossum_phase += delta * 0.7
var curve := sin(_opossum_phase) * 0.35 # Curvy wander adjustment
# ... Apply position and rotate the opossum to look in the heading direction

🌲 Procedural Spatial Layout (Forest Generation)

To ensure the environment looks organic but never clips through UI elements or the camera's sightline, the mushroom forest is generated procedurally on startup in main.gd.

The layout logic employs a simplified Poisson Disk-like clearance check:

It maintains an array _occupied containing [Vector2, radius] pairs of existing assets.
It attempts to generate coordinates within a ring (distance 9 to 22 units from the center).
It filters out coordinates that block the gnomes (center ground) or the camera sightline (z > 0.0 check).
It calls a clearance validation:

func _is_clear(x: float, z: float, radius: float) -> bool:
	var p := Vector2(x, z)
	for o in _occupied:
		if p.distance_to(o[0]) < radius + float(o[1]):
			return false # Too close to another object
	return true

Only if the check returns true is the mushroom instantiated, scaled randomly, rotated randomly, and placed.

🎮 Play & Inspect

Metrognome is a fun reminder of why building small, self-contained utilities is such a rewarding exercise. It blends audio programming, basic linear algebra, and aesthetics into a neat, 30MB HTML5 bundle.

Play it in your browser: Metrognome on itch.io
Browse the source code: ianlintner/metrognome on GitHub

Next time you need a practice click for your guitar, synth, or drums—why not let some gnomes handle it?
